2. Use the / CHASE 1 to30 / buttons to select the desired sequence.
3. Press the / JOG MODE / button to move the joystick to TIME mode. / TIME / -LED lights.
4. Now you can set the flow speed with the / WAIT / -xe of the joystick and the fade time with the / FADE / -exe.
The values are displayed in seconds when the display is set

2.4 MIDI-Operation:

The device can be controlled via MIDI, Such as a MIDI keyboard or sequencer software.
For MIDI control, the device must be set to the MIDI channel through which it is to be controlled:
1) Hold down the / MIDI / REC / button until the display shows:
2) Select the MIDI channel using the / UP / and / DOWN /
3) Press the / MIDI / REC / button for two seconds to save the setting and exit.
So the Midi-Functions are occupied:
Bank
Scene 1 - 30
Chases 1-30
AUX1
AUX2
UP
DOWN
TAP
BLACK OUT

2.5 Blackout-Function:

Press the / BLACKOUT / button to turn off all connected headlights. Another push-button
Returns to the previous brightness.

2.6 USB Connection:

Data can be stored and read via the USB socket (USB stick). The entire memory content (scenes, chases) of the
Note number
00
01
02
03
04
05
------------------------
25
26
27
28
29
30
31
32
33
-------------------------
55
56
57
58
59
60
61
62
63
64
126
28
Function
Scene 1 On/Off
Scene 2 On/Off
Scene 3 On/Off
Scene 4 On/Off
Scene 5 On/Off
Scene 6 On/Off
----------------------
Scene 26 On/Off
Scene 27 On/Off
Scene 28 On/Off
Scene 29 On/Off
Scene 30 On/Off
Chase 1 On/Off
Chase 2 On/Off
Chase 3 On/Off
Chase 4 On/Off
------------------------
Chase 26 On/Off
Chase 27 On/Off
Chase 28 On/Off
Chase 29 On/Off
Chase 30 On/Off
Freely defined
Freely defined
Freely defined
Freely defined
Freely defined
Black Out
