d) Discharging mode

• Press and hold the "MODE" button (> 1 second) and then select the discharging mode by
pressing the "MODE" button again.
• Press "CURRENT" button to select discharging current (100, 250 and 350mA).
• After the rechargeable battery is fully discharged, the charging process will start automatically.
The charging current (200, 500, 700mA) is double of the selected discharging current.
• Press "DISPLAY" button to scroll through different displays, charging current (mA), battery
voltage (V), accumulated capacities (mAh) or time elapsed (hh:mm).
Stage in charging mode
During discharging
During charging
During trickle charging
e) Refresh mode
• Press and hold the "MODE" button (> 1 second) and then select the refresh mode by pressing
the "MODE" button again.
• Press "CURRENT" to select the discharging current (200, 500, 700mA). The charging current
(200, 500, 700mA) is double of the selected discharging current.
• Press "DISPLAY" button to scroll through different displays, charging current (mA), battery
voltage (V), accumulated capacities (mAh) or time elapsed (hh:mm).
Stage in charging mode
During discharging
During charging
During trickle charging
24
Current (mA)
Discharging
current
Charging current
Trickle charging
current
Current (mA)
Discharging
current
Charging current
Trickle charging
current
Voltage (V)
Instantaneous
battery voltage
Accumulated
Voltage (V)
Instantaneous
determined in
battery voltage
Accumulated
Capacity Time
(mAh/Ah) (hh:mm)*
Capacity
Discharging
during
time elapsed
discharging
Charging
capacity time elapsed
Capacity Time
(mAh/Ah) (hh:mm)*
Capacity
Discharging
during
time elapsed
discharging
Capacity
Charging
time elapsed
discharging
Last
discharging
capacity
time elapsed
