SEW-Eurodrive CMP40 - 100 Betriebsanleitung Seite 9

Hybridkabel Motoren CMP. in geberloser Ausführung
Motoren CMP ohne Bremse
Motor Bemessungs-
drehzahl
CMP. 1/min
40S 3000 – 6000
40M 3000 – 6000
50S 3000 – 6000
50M 3000 – 6000
50L 3000 – 6000
63S 3000 – 6000
63M 3000 – 6000
63L 3000 – 6000
63L 6000
71S 2000 – 3000
71S 4500
71S 4500
71S 6000
71S 6000
71M 2000
71M 3000
71M 3000
71M 4500
71M 4500
71M 6000
71M 6000
71L 2000
71L 3000
71L 3000
71L 4500
71L 4500
71L 6000
80S 2000
80S 3000
80S 3000
80S 4500
80S 4500
80S 6000
80S 6000
80M 2000
80M 2000
80M 3000
80M 3000
80M 4500
80M 4500 – 6000
80L 2000
80L 2000 – 3000
80L 4500
80L 6000
100S 2000
100S 2000
100S 3000
100S 3000
100S 4500
Motor in geberloser Ausführung anschließen mit Steckverbinder SH.
Aderquerschnitt Steckverbinder
2
mm
4×1.5
4×1.5
4×1.5
4×1.5
4×1.5
4×1.5
4×1.5
4×1.5
4×2.5
4×1.5
4×1.5
4×2.5
4×1.5
4×2.5
4×1.5
4×1.5
4×2.5
4×1.5
4×2.5
4×2.5
4×4
4×1.5
4×1.5
4×2.5
4×2.5
4×4
4×4
4×1.5
4×1.5
4×2.5
4×2.5
4×4
4×4
4×6
4×1.5
4×2.5
4×2.5
4×4
4×4
4×6
4×2.5
4×4
4×6
4×10
4×2.5
4×4
4×4
4×6
4×6
max.
Kabellänge
m Schleppkettenver-
SH1 100
SH1 100
SH1 100
SH1 100
SH1 100
SH1 100
SH1 100
SH1 75
SH1 100
SH1 100
SH1 95
SH1 100
SH1 70
SH1 100
SH1 100
SH1 90
SH1 100
SH1 65
SH1 100
SH1 80
SH1 100
SH1 100
SH1 80
SH1 100
SH1 85
SH1 100
SH1 100
SH1 100
SH1 70
SH1 100
SH1 80
SH1 100
SH1 95
SHB 100
SH1 75
SH1 100
SH1 90
SH1 100
SH1 95
SHB 100
SH1 90
SH1 100
SHB 100
SHB 100
SH1 85
SH1 100
SH1 95
SHB 100
SHB 98
Zusatz zur Betriebsanleitung – CMP40 – 100, CMPZ71 – 100
Elektrische Installation
Sachnummer
schleppfähige
legung Verlängerung
18177018 18177069
18177018 18177069
18177018 18177069
18177018 18177069
18177018 18177069
18177018 18177069
18177018 18177069
18177018 18177069
18177026 18177077
18177018 18177069
18177018 18177069
18177026 18177077
18177018 18177069
18177026 18177077
18177018 18177069
18177018 18177069
18177026 18177077
18177018 18177069
18177026 18177077
18177026 18177077
18177034 18177085
18177018 18177069
18177018 18177069
18177026 18177077
18177026 18177077
18177034 18177085
18177034 18177085
18177018 18177069
18177018 18177069
18177026 18177077
18177026 18177077
18177034 18177085
18177034 18177085
18177042 18177093
18177018 18177069
18177026 18177077
18177026 18177077
18177034 18177085
18177034 18177085
18177042 18177093
18177026 18177077
18177034 18177085
18177042 18177093
18177050 18177107
18177026 18177077
18177034 18177085
18177034 18177085
18177042 18177093
18177042 18177093
