PG-C20XU
PG-C20XE
AN-Z7T
Remote Control/Mouse Receiver Positioning
The remote control can be used to control the projector within the ranges shown below.
The remote mouse receiver can be used with the remote control to control the mouse functions of a connected
computer within the ranges shown below.
The signal from the remote control can be reflected off a screen for easy operation. However, the effective distance of the
signal may differ due to the screen material.
Controlling the Projector
Remote control
23' (7 m)
30ß
30ß
Effective buttons in MOUSE mode
Remote control
(Front view)
Remote control
(Rear view)
45ß
45ß
30ß
Remote control
Mouse
MOUSE
RIGHT-CLICK
AV MUTE
LEFT-CLICK
Using the Wireless Mouse
Remote control
30ß
30ß
13' (4 m)
Remote
mouse
receiver
Using as a Wireless Mouse
When MOUSE is pressed, the buttons on the remote
control light up and the remote control enters MOUSE
mode.
During MOUSE mode, the cursor can be used as the
pointer. MOUSE mode is for about ten seconds while
the buttons are lighting.
When MENU or ENLARGE is pressed, MOUSE mode
is released to the normal mode.
Be sure the supplied remote mouse receiver is
connected to your computer.
The wireless mouse may not operate correctly if your
computer serial port is not correctly set up. Refer to the
computer s operation manual for details of setting up/
installing the mouse driver.
For one-button mouse systems, use either the LEFT-CLICK
or RIGHT-CLICK button.
10
120ß
