4. INSTALLATION
4.3 TP Scan
When you enter "TP Scan" menu a window
like the one beside will be displayed.
1. In the "Satellite" item press [Vol
select the satellite which you want to scan
or press [OK] to open the "satellite list" to
select directly with [CH
to confirm it.
2. TP Index: Use [Vol
list to select directly with [CH
the channel can be found. Press [Red/Green/Yellow] key on the RCU for the related
functions.
• When you press [Red] it will display "New TP" in "TP Index" item. You have to set the
parameters of "TP Frequency", "Symbol Rate" for this new transponder. Therefore
use the number buttons of the RCU. The available range are "3000 ~ 13450MHz" and
"1000 ~ 45000KS/s".
• When you press [Green] a safety question will be displayed for confirmation to delete the
current transponder or not. If you select "OK", the current transponder will be deleted
and the total number of transponders will be reduced.
• When you press [Yellow] a safety question will be displayed for confirmation to delete all
transponders or not. If you select "OK", the all transponders on current satellite will be
deleted.
3. For existing transponders you also can use number buttons to modify the parameters
of "TP Frequency" and "Symbol Rate" or [Vol
"Polarity" and "FTA only" are used for setting scans conditions. Press [Vol
a different mode.
• On "TP Scan" item, press [OK] will open another window where you can set "Scan
Mode", "Program Type" and "NIT Search". Press [Menu/Exit] to return to the
previous menu.
• Press [Red] button to add a new TP.
• Press [Green] button to delete the current TP.
• Press [Yellow] button to delete all transponders on current satellite
4. Antenna Setup: Press [OK] to enter LNB configuration, you will see a window like beside:
] to
], press [OK]
] to select the desired transponder or press [OK] to open the TP
], press [OK] again to display the TP number where
29
] to change the value directly.
] to select
DVB-S Receiver
GB
