Installation and Connection
2.2.10 Motor connection
The power connector may only be connected / disconnected when the device and the power
supply are disconnected !
Observe correct phase sequence of the servo motor !
B
C
A
D
4
1
3
2
Servo motor
Power connector
2
PE
1
U
4
V
3
W
C
PTC-connection
D
PTC-connection
A
Brake +
B
Brake –
Motor housing /
screw connection
Connector
Pin No.
1
4
3
2
A
B
C
D
Connect shielding at both
sides
with large surface !
Name
U
V
W
PE
Brake +
Brake –
PTC-Contact
PTC-Contact
PE
U
V
W
PA
PB
T1
T2
external brake supply
unit with own voltage
supply
Cable
Core No.
1
2
3
green-yellow
5
6
7
8
GB - 9
