Please open the fold-out page with the
illustration of the unit and leave it open
while you read these operating instruc-
tions.
Intended Use
The tool is intended for the screwing in and loosening
of bolts and screws as well as for the tightening and
loosening of nuts in the specified dimension and per-
formance range.
Product Elements
The numbering of the product elements refers to the
illustration on the fold-out page.
1 Insertion tool (e.g. socket nut)*
2 Tool holder
3 Angled drive head
4 Open-ended spanner (27 mm)
5 Spanner flats on the angled head flange
6 Open-ended spanner (22 mm)
7 Slide (torque setting)
8 Hanging hoop
9 LED indicator, tightening control
10 LED Indicator, battery condition
11 Battery-pack*
12 Battery release button
Product Specifications
Industrial Cordless Angle Wrench
Order number 0 602 490 ...
Tightening torque
No-load speed
Voltage
Rotational direction
Tool holder
Delivered items
Battery-pack
Angled drive head
Weight (without accessories) approx.
3 609 929 879 • (03.02) T
3 FUNCTION
Noise/Vibration Information
Measured sound values determined in accordance
with EN ISO15 744. Measuring inaccuracy 3 dB(A).
Measured vibrational values determined in accord-
ance with EN 28 662 and EN ISO 8662.
The A-weighted sound pressure level of the product is
typically 70 dB(A). The noise level when working can
exceed 85 dB(A).
Wear ear protection!
The hand-arm-acceleration is typically below 2.5 m/s
Measuring inaccuracy K = 1.2 m/s
13 On/Off switch
14 Right/Left switching with centre lock
15 Slots for hanging hoop
16 LED holder
17 Spanner flats on the sleeve nut
18 Coloured ring (for identifying torque range)
19 Spring ring
20 Cavity in the housing shell
21 LED work area illumination lamp
22 Adjustment disc for the setting of the torque
23 Adjustment tool
24 Allen key
* Optional accessories
Not all the accessories illustrated or described are in-
cluded in standard delivery.
... 635
[Nm]
-1
[min
]
[V]
s 3/8"
[kg]
English–4
15
15
... 636
... 637
15
15
250
250
420
9.6
9.6
9.6
s 3/8"
s 3/8"
q
–
q
q
1.2
1.7
1.2
2
.
2
.
8
8
8
... 638
... 643
8
8
8
420
420
9.6
9.6
s 3/8"
s 1/4"
q
–
–
q
q
q
1.7
1.2
