SAT OUTPUT
Alternatively, use the speakON socket in the recessed handle on the top of the subwoofer to connect the CURV 500 SmartLink adapter to the
speakON socket on the back of the subwoofer. If you wish to set up the satellites on the spacer rod and separate stand (optional), use the
two speakON speaker sockets (maximum number of satellites per system is six, one double satellite is equivalent to two single satellites).
16
M20 THREAD
M20 thread to attach the speaker spacer rod.

CURV 500 SATELLITES AND SMARTLINK ADAPTER
