1
LINE INPUT
Symmetrical line input (XLR).
2
MAIN LEVEL
Control for overall volume. Turn anti-clockwise to reduce overall volume and clockwise to increase overall volume.
3
SUB LEVEL
Set volume of the subwoofer relative to the satellite speakers.
4
POWER LED
The power LED goes on when the device is correctly connected to the mains and switched on.
5
SIGNAL / LIMIT LED
Two-colour display LED. The LED lights up green when the device is receiving an audio signal. The LED lights up red when the speaker
system is being operated in the upper threshold range. Brief illumination of the LED is uncritical here. In order to protect the system, an
excessive signal level is gently down-regulated by the integrated limiter. If the limiter LED lights up for a prolonged period or permanently,
reduce the volume level. Failure to do so can result in distorted sound reproduction and cause damage to the speaker system.
6
THRU
Male 3-pin XLR socket for sending the audio signal received at LINE INPUT.
7
SAT
Neutrik speakON speaker socket for connecting the CURV 500 SmartLink adapter. Alternatively, you can use the speakON socket in the
recessed handle on the top of the subwoofer (suitable speaker cable supplied). If you wish to set up the satellites on the spacer rod and
separate stand (optional), use the two speakON speaker sockets (maximum number of satellites per system is six, one double satellite is
equivalent to two single satellites).
8
NUMBER OF SATELLITES - SET-UP
Button to adapt the DSP settings to the number of satellite speakers being used per SmartLink adapter (here, one double satellite is equiva-
lent to two single satellites). Press the button until the relevant number of display LEDs light up (see also "CONFIGURATION EXAMPLES").
9
NUMBER OF SATELLITES - LED 1–6
LEDs for displaying the currently activated DSP presets.
10
POWER IN
Neutrik powerCON mains socket. A suitable power cable is included.
12
POWER ON/OFF
On/off switch for power supply to the device.
12
FUSE
Fuse holder. IMPORTANT: When replacing the fuse, only use a fuse of the same type and value. Follow the instructions printed on the hous-
ing. In the event of repeated fuse failure, please contact an authorised service centre.
13
HOUSING FAN
In order to avoid overheating of the device, ensure that the fan is not obstructed and that air can circulate freely.
14
VENTILATION GRILL
In order to avoid overheating of the device, ensure that the ventilation grill is not covered and that air can circulate freely.
