5.3
Fig 14: Dimensions, measuring tube temperature

5.3 WMZ 32

5.3.1 Device information overview

Performance data
Permissible volume flow measuring range
Permissible temperature measuring range
Operating temperature
Storage temperature
Hydraulic connection
Max. operating pressure
Fig 15: Device information, WMZ 32

5.3.2 Maximum deviation

Fig 16: Maximum temperature and volume flow deviations
EN-12
2000l/h to 5000l/h
25 °C to 80 °C
0°C to 35°C
-15°C to 60°C
Both pipes 1 1/4" each
3 bar
volume flow [l/H]
