Assembly and usage of the chassis

1
2
2
3
3
4
5
4
18
Unfolding the chassis
• Start by braking the pram.
• Pull the handle while you are holding one side of the chassis.
WARNING
• The chassis locks need to click into the locked position.
• The safety catch (secondary locking mechanism) is activated to
prevent unintentional folding if the chassis lock is not locked into
position.
• Please make sure, before you use the pram that the chassis lock is
in the locked position.
Attaching the wheels
• Remove the plastic protection from the axles. Save them for future
1
use.
• Attach the wheels with the wheel cogs (1). Press in the hub cap's
release button (2), push the wheel onto the axles as far as it can go.
Release the button and pull the wheel towards you, until you hear a
definite click. Repeat the same procedure for all four wheels. Please
make sure that the wheels are attached properly and cannot be
pulled off the axle.
• Release the brake by pushing the brake bar up towards you using
minimum force with your foot.
IMPORTANT
• The wheels are greased and can leave marks on textiles. Please use
wheel protection indoors to protect your floors.
• Risk of suffocation. Don't let your child play with or in some other
way handle the plastic protections.
• Because of the influence of ozone and UV radiation the tyres may
develop small cracks due to the rubber drying out. This does not
affect the vehicle's driving ability and safety and is not a reason for
complaint.
Engaging the Parking Device
• Engage the parking device by pushing down with your foot.
• Disengage the parking device by pulling up.
WARNING
• Never leave the vehicle without first engaging the parking device.
• Avoid uphill or downhill parking.
• The pram's brake should always be engaged when you lift your
child in and out of the pram.
• Make sure that the cogs are attached properly on all 4 wheels
• Make sure that the brake pin engages into the cogs when the vehicle
is in parked position.
How to adjust the height of the handle
• Adjust the height on the handle by pressing the grey buttons on the
inside of the handle (4).
Keep the buttons pressed in while you adjust to the required
position (5).
Manual Cerox v. 1.6
