2. Installation and Operation

There are two different types of online UPS: standard and long-run models. Please refer to the following
model table.

2-1. Unpacking and Inspection

Unpack the package and check the package contents. The shipping package contains:
● One UPS
● One user manual
● One monitoring software CD
● One RS-232 cable (option)
● One USB cable
● One battery cable (option)
NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged
during transportation. Do not turn on the unit and notify the carrier and dealer immediately if there is any
damage or lacking of some parts. Please keep the original package in a safe place for future use.

2-2. Rear Panel View

Diagram1: 6K/10K Rear Panel
Model Type
Standard
6K
model
Standard
10K
model
Model
Long-run
6KL
Long-run
10KL
5
Type
model
model
