Installation
Testing / Adjustment
Mixture-control device for natural gas / Propane gas
2
1
30
Conversion to propane gas
operation
· Remove gas diffusor 3 and turbulator
4.
· Fit distance piece 5 (supplied with
burner body).
· Refit turbulator 4 and gas diffusor 3.
Fitting burner head
· Place O-ring J in groove of gas
connection flange.
· Install the burner head.
· Secure cover (3 screws S in twist and
lock).
· Insert ionisation cable IK into
connection base.
· Connect ignition cable ZK to ignition
transformer.
03/2005 - Art. Nr. 13 018 069A
Check the burner head
· Check adjustment settings of
ionisation probe 1 and ignition
electrode 2 as per specifications
given.
