– Plug the power supply into a mains
socket.
– Push the connector of the power supply
into the socket (15).
The charging status is displayed by the con-
trol lights (13) and (14):
• Both control lamps light up = battery is
charging.
• Red control lamp (13) goes out, green
control lamp (14) lights up = battery fully
charged.
– Slot the battery pack into the device and
make sure it clicks into place correctly.
Checking the remaining capacity of
the battery
► P. 3, item 1
– Press the button (6).
– The remaining capacity of the battery is
shown by the display (7).

Battery-powered screwdriver

Removing a tool
CAUTION!
Risk of injury!
Shortly after being used, the tool may
be very hot. Risk of burning! Allow a
hot tool to cool down. Never clean a
hot tool with flammable liquids.
– Set the rotation direction switch (3) to the
centre setting.
– Turn the tool holder (1) anti-clockwise.
– Remove the tool.
Inserting a tool
WARNING!
Risk of injury!
Make sure that when installing the
tool that it fits securely in the clamp-
ing chuck and is not at an angle.
– Place the tool as far as it will go into the
tool holder (1).
– Set the rotation direction switch (3) to the
centre setting.
– Turn the tool holder (1) clockwise and
secure.
Changing the rotation direction
NOTICE!
Risk of damage to the unit!
Only use the rotation direction switch
when the device is at a standstill.
– To drill and screw screws into place,
press the rotation direction switch (3) to
the left (rotation in clockwise direction).
– To remove screws, press the rotation
direction switch (3) to the right (rotation in
an anti-clockwise direction).
Note:
If the rotation direction switch is in
the centre position, the On/Off
switch (8) is blocked.
Setting the torque
NOTICE!
Risk of damage to the unit!
Only use the torque regulator when
the device is at a standstill.
NOTICE!
Risk of damage to the unit!
Do not use the setting [
screwing in screws.
The torque of the device can be adjusted to
24 different settings by turning the torque
regulator (2):
• Settings 1–10 = Low setting for small
screws and soft materials.
• Settings 11-23 = Higher settings for
larger screws and harder materials.
] = For drilling and unscrew-
• Setting [
ing tight fitting screws. The releasing
clutch is without function during this set-
ting: The device operates at maximum
torque.
Switching on and off
– To start the tool turning, press the On/Off
button (8).
– To switch the unit off, release the On/Off
switch (8).
GB
]for
