GB
Wear tight fitting clothes when work-
ing with the device.
If you have long hair, cover or wear a
hair net.

Your unit at a glance

Battery-powered screwdriver

► P. 3, item 1
1. Tool holder
2. Torque regulator
3. Rotation direction switch
4. Locking button
5. Battery pack
6. Button for remaining capacity
7. Display for remaining capacity
8. On/Off switch
9. LED

Battery-powered work light

► P. 4, item 2
10. On/Off switch
11. Reflector (can be swivelled)
4. Locking button
5. Battery pack

Battery charger

► P. 4, item 3
12. Battery charger
13. Control light (red)
14. Control light (green)
15. Socket for power supply

Scope of delivery

• Operating manual
• Battery-powered screwdriver
• Battery-powered work light
• Drill (6×)
• Screwdriver bit (6×)
• Battery charger
• Mains adapter
• Battery pack (2×)
48
Note:
If any one of the parts is missing or
damaged, contact the retailer.

Operation

Check before switching on!

– Check to make sure the device is in a safe
operating condition:
– Check to make sure there are no visible
defects.
– Check to make sure all device compo-
nents are correctly mounted.

Charging the battery pack

NOTICE!
Risk of damage to the unit!
Do not allow the battery pack to deep
discharge.
NOTICE!
Risk of damage to the unit!
Do not press the On/Off switch after
the device has deactivated automat-
ically.
Note:
The Li-Ion battery pack can be
charged at any time without affecting
the lifetime of the unit. Interrupting
the charging process will not dam-
age the battery pack.
Note:
If the battery is fully loaded, the
charger automatically switches over
to the maintenance charge function.
The battery can thus remain in the
charger permanently.
• The battery pack must be charged prior
to the first start-up (charging time:
► Technical data – p. 51).
– Press in the locking button (4) and
remove the battery from the device
(► P. 5, item 4).
– Insert the battery pack into the
charger (► P. 5, item 5).
