DESCRIPTION OF THE DEVICE

Features

LED Moving Head spot with 150 W LED and rotating 8-facet prism
• Equipped with a white 150 W COB LED
Lightbeam with 4° radiation angle
•
Positioning within 540° PAN and 280° TILT
•
Exact positioning via 16 bit PAN/TILT movement resolution
•
Flicker-free projection
•
DMX-controlled operation or stand-alone operation with Master/Slave function
•
Sound-controlled via built-in microphone
•
Macros
•
Color wheel with 8 dichroic color filters and white
•
Rainbow effect with adjustable speed
•
Rotating 8-facet prism
•
The prism rotates in both directions and at different speeds
•
Gobo-wheel with 8 gobos plus open
•
With gobo shake function
•
• Frost-filter
• Strobe effect with variable speed
• Internal programs
Dimmer
•
Motorized focus
•
Fan-cooled
•
Control board with LC display and four operating buttons for adjusting the DMX-starting address,
•
PAN/TILT reverse, reset
Switch-mode power supply for operation between 100 and 240 volts
•
P-Con power input and feed-through output to power up to 8 devices
•
DMX control via any standard DMX controller
•

Overview

1
2
(1) Lens
(2) Projector head
(3) Ventilation grille
(4) Yoke
3
(5) Base
4
(6) Carrying handle
(7) Rubber foot
5
6
7
23/36 00111883, Version 1.0
