Notes for professional electricians

Installation and basic settings:
1. Switch off the power supply.
2. Connect the supporting frame terminal according to the wiring dia-
gram (see page 66).
Attention: Currently valid VDE standards must be observed
when connecting the device, in particular DIN VDE
0100/0700 as well as the currently valid regulations
of your local power company and accident preven-
tion regulations.
3. Mount the supporting frame in the flush-type box.
4. Slide the combination frame carefully in the supporting frame so that
the centring pins of the supporting frame fix the frame in the centre.
5. Slide the basic housing in the supporting frame.
6. Switch on the power supply and press the reset button.
7. Check, if the direction of the motor rotation corresponds with the
direction buttons. If not, exchange terminal 4 with terminal 5.
12:17 Seite 65
Installation
- 63 -
Installation
Important: Parallel control of several roller shutter drive motors can
only be implemented by means of isolating relays or
group control devices.
For trouble-free operation of all storing functions, it is
necessary that the Vestamatic Rolltec Pro roller shutter
control is connected to the line voltage for approx. 1 hour.
The following versions of cover frame Jung "CD 500", alpine-white,
are available:
Combination frame one-fold,
Combination frame two-fold,
Combination frame three-fold,
Combination frame four-fold,
Combination frame five-fold,
For surface-type installation
please use our surface-type housing,
For controlling two drives, we recommend our isolating relays:
Isolating relays TR N2S,
Isolating relays TR N2A,
G G
Notes for professional electricians
article-no. 01400201
article-no. 01400202
article-no. 01400203
article-no. 01400204
article-no. 01400205
article-no. 01030753
article-no. 01054220
article-no. 01054120.
