CONNECTING THE DN 50 SUCTION LINE

Fig. 2 Connecting the vacuum and vent system
1. Lead the suction line (RAUPIANO PLUS DN 50) to
either the right or left connector.
2. Using a double socket (included in the standard
delivery) directly connect the vacuum line to the
central vacuum unit.
3. Using a dummy plug (included in the standard
delivery) to block off the open connector.
Where two rising pipes are employed, the suction
lines can be connected to both the left and right
connectors on the central vacuum unit.
DN 50
