PREPARATIONS

The system can be operated by either a radio control,
control cable or a combination of radio and cable
control.
Depending on the selected method of operation,
one of the following steps must be carried out for
commissioning..

Connecting the Central Vacuum Unit

1. Make sure the central vacuum unit has been turned
off at the main power switch (refer Fig. 7).
2. Plug the connecting cable into the on-site grounded
outlet (230 V, 16 A Europe/10 A CH).
3. Turn the central vacuum unit's main power switch
on.
Fig. 7 Central vacuum unit's main power switch
I ON 0 OFF

Preparations for Radio Operation

In order to use radio operation to turn the central
vacuum unit on and off, the transmitter in the handle of
the suction hose RC must first be taught to recognize
the central vacuum unit.
Additional VACUCLEAN transmitter units („manual
transmitters") can also be taught. Up to a maximum
of 16 transmitters can be taught. Teaching the 17
transmitter overwrites the information in the 16
transmitter.
30

General Notes

- Because of easier accessibility, transmitters should
be taught on the floor prior to mounting the central
vacuum unit on the wall.
- When new, the LCD display on the central vacuum
unit reads „000h" hours of operation. While the
transmitters are being taught, the display changes
to the teaching and delete mode. In this mode,
additional system and status information is displayed
(see below).
- If the central vacuum unit's main power switch is
turned off during ongoing teaching or delete pro-
cesses, all active teaching and delete activities will
be interrupted.
Ir required, teaching or delte processes can be
restarted by switching the unit's power off and on.
