OPERATION USING A CONTROL CABLE

System Components

The following information applies to the operation of
the system via control cable
The following components are suitable for proper use and are to be employed as required:
Part
VACUCLEAN suction socket
VACUCLEAN surface mounted installation
housing CC
VACUCLEAN control cable
VACUCLEAN basic vacuum set CC
VACUCLEAN basis package CC
Table. 1 Components for VACUCLEAN operation with control cable
Part no.
243302-002 Material: Aluminium
Wall socket 243588-001 Material: ABS
243598-001 Material: ABS
Floor socket 242313-001 Material: Aluminium
243362-003 Fully assembled
243472-001
352352-002
245577-001
Notes
2-lead
Diameter: 2 x 0.75 mm 2
Length: 15 m
Comprising:
- Suction hose CC (8 meters)
- Handle with vacuum air regulation
- Telescopic tube
- Combination nozzle with protective cover
- Corner nozzle
- Upholstery nozzle
- Hose holder
For shell installation (single family home).
- 3 suction sockets (aluminium, white)
- 3 plaster covers
- 3 mounting frames
- 10 RAUPIANO PLUS bends DN 50 45°
- 1 vent flap
- 3 reduced suction socket connecting bends DN 50 90°,
(incl. lip seal ring)
- 1 control cable (15 meters)
Color: White (similar to RAL 9003)
Color: Polished chrome
Color: Matte chrome
Color: Bronze
Color: White (similar to RAL 9003)
