The subject-heading for information may be
located in colored box.
"-P/CH" or "P/CH+" com-
In TOP mode the
mands will request the next or previous page
respectively. If TOP text transmission is not
available, in case of operation of these com-
mands, wraparound occurs. For example page
100 appears to be one greater than page 199.

To exit Teletext

• Press the " " button. The screen will
switch to TV mode.

To Display the Time

• While watching a TV programme with Teletext
transmission press "
time information, captured from Teletext will be
displayed at the upper right of the screen until
the " ", " " or "M" button pressed.
• If the programme being watched does not
have Teletext transmission, no information
will be displayed.
Peripheral Equipment
Connections
There is a wide range of audio and video
equipment that can be connected to your TV.
Connection diagrams at the end of this sec-
tion show you where the different equipment
should be connected at the back or right
side of the TV.

PC Sound Connection

• Connect the PC Audio output to the TFT PC
Audio In socket with stereo connection
cable.
• In the main menu select "Feature" by using
" " or " " button then enter the Feature
menu by pressing " ", " " or "OK" button.
Come on "PC Sound Mode" by using " " or
" " button and select PC from the TV, AV-1,
AV-2, AV-3 and PC options by using " ", " "
or "OK" button.
• Source also should be selected as PC in
the main menu.
ENG-2707W-1543 UK-27 INCH TFT (17MB08)-DUVAR MON-(WO PIP)(CHI MEI-B1).p65

Via the Euroconnector

Your TV set has 2 Euroconnector sockets. If
you want to connect peripherals (e.g. video,
" button. The current
decoder, etc.) which have Euroconnectors,
to your TV, use SCART input.
If an external device is connected via Euro-
connector sockets TV is switched to AV
mode automatically. In this case if both
sockets are connected, SCART-1 has the
precedence.

Via Ant Input

If you want to connect to your TV, peripherals
like video recorders or decoders, but the de-
vice you want to connect does not have
Euroconnector, you should connect it to the
ANT input of your TV set.
If the VCR is connected via antenna input
it is suggested to use the Programme 0.

Decoder

Cable TV offers you a wide choice of
programmes. Most of them are free, others
are to be paid for by the viewer. This means
that you will need to subscribe to the broad-
casting organisation whose programmes
you wish to receive. This organisation will
supply you a corresponding decoder unit to
allow the programmes to be unscrambled.
For further information ask your dealer. See
also the booklet supplied with your decoder.
Connect a decoder with an aerial socket
to the TV
• Connect the aerial cable.
- 25 -
25
TFT side PC side
PC Audio In PC Audio Output
