Dual DTFT 27-2 N Bedienungsanleitung Seite 114

Setting H.Phone/Line Out Sound Mode
• Using " " or " " button select Sound Mode.
Pressing " " or " " button will change the
current sound mode. (e.g.: If the current sound
mode is stereo, it will be stereo or visa versa).
In case of bilingual broadcast, you can se-
lect original or dubbed language again us-
ing mode menu. So when somebody listens
to the original language from the loudspeak-
ers, somebody else can listen to the dubbed
language from headphone.
To Store the Settings
• Press "OK" button on the remote control to
store the settings directly.
or,
• Using " " or " " button select Store. Press " ",
" " or "OK" button to store current H.Phone/
Line Out volume and sound mode. The stored
values will be valid for all the programmes.
Equalizer
• Using " " or " " button select Equalizer. .
• Press " " or " " button or directly press
"OK" button to enter Equalizer sub-menu.
Sound
Equalizer . . .
In Mode item there are five predefined and
one user defined options. These are User,
ENG-2707W-1543 UK-27 INCH TFT (17MB08)-DUVAR MON-(WO PIP)(CHI MEI-B1).p65
Flat, Pop, Rock, Jazz and Classic. The pre-
defined options can not be changed by the
user. If you want to change one of the fre-
quency values of the predefined options, the
Mode must be switched to User option.
The 5 items above the Mode are available to
adjust the sound settings in 5 frequency val-
ues: 120 Hz, 500 Hz, 1.5 kHz, 5 kHz and 10
kHz. To change the values of 5 frequency op-
tions, select one of the options by " " or " "
button, and then press " " to increase the
value, or " " to decrease the value. In mid
position, cursor is displayed with one arrow.
To store the Equalizer settings, press " " or
" " button or directly press "OK" button on
"Store" option.
During the store process all the items are
stored, moreover, the User mode information
would not be lost. In other words, when the
user mode is selected again, after storing the
Mode with one of the predefined options, the
user defined frequency values would be set.
Setting AVL
• Using " " or " " button select AVL.
• Pressing " " or " " button will turn on and
off this feature.
Automatic Volume Limiting (Avl) function
normalises sound to obtain fixed output
level between programmes, having different
sound levels.
To Store the Settings
• When the cursor is on any item which has
no sub-menu press "OK" button on the re-
mote control to store the settings directly.
or,
- 13 -
13
Sound
On
30.05.2006, 16:36
