Sleep Timer Indicator; Mute Indicator; No-Signal Detection (Tv); No-Signal Detection (Pc) - Dual DTFT 27-2 N Bedienungsanleitung

Sleep Timer Indicator

It is displayed on the upper right of the
screen when a new programme is entered
by digit button or by pressing "P<P", "-P/CH",
"P/CH+"
, " ", "
timer is activated it is displayed with the TV
status and erased with it after 3 seconds.
In last minute, sleep timer indicator is dis-
played on the upper right of screen and
stays there until the TV goes automatically
to stand-by.
0:15

Mute Indicator

It is placed in the upper middle of the screen
when enabled, and it stays there until it is
disabled.
To cancel mute, there are two alternatives;
the first one is pressing to " " button, this
volume is set to the preceding value, and the
second one is increasing the volume level,
thus it starts at the minimum level to in-
crease. By decreasing the volume level in
mute state, mute will not be ignored, only the
volume level will decrease. If mute is can-
celled after decreasing the volume level, the
volume will be valid with the decreased
level.

No-Signal Detection (TV)

If no valid signal detected, it takes 5 minutes
for the switching to the Stand-By mode un-
less any signal detected or no any Remote
Control command is accessed.
After a Remote Control command (if No-Sig-
nal Timer is active) the timer stops and if no
signal detected again the timer is initialized
to 5 minutes and starts 3 seconds later
again to count down.
It is not valid in AV mode.
4:31
ENG-2707W-1543 UK-27 INCH TFT (17MB08)-DUVAR MON-(WO PIP)(CHI MEI-B1).p65
" or " " button. If sleep
- 21 -
21

No-Signal Detection (PC)

If no valid signal detected for 5 minutes sys-
tem goes to Stand-By mode. To switch on
the system press " " button.
As the last status feature, system starts from
TV or PC, whichever was the status before
stand-by or switch-off. Note that SCART in-
puts have the precedence on both TV and
PC.

Volume Bar

It is displayed in the lower middle of the
screen. When a volume command is re-
ceived (pressing " +" or "
mote Control or Control panel at the top of
the TV) and no menu is active, it stays on the
screen for 3 seconds, after the last volume
command or until another command is re-
ceived in between.

AV Modes

By pressing the " " button you can switch
your TV to AV modes (except being in Tele-
text). Pressing this button consecutively will
switch the TV in one of the optional AV
modes: AV-1, AV-2, AV-3, S-VIDEO, PC.
In order to quit the AV mode press the "
digit buttons or "-P/CH" or "P/CH+" .

Signal Out Of Range

When the PC input signal is not supported
by LCD-TFT TV, a message is displayed like
"Signal out of range" and screen is blanked.
If no valid signal detected for 5 minutes sys-
tem goes to Stand-By mode.
30.05.2006, 16:36
-" by Re-
",
