Installation

Information

A
Caution!
Functional limitation due to faulty recess of the lock pocket: The lock pocket
must be created corresponding to the lock case dimensions. You must insert the
lock without using any force and screw it into place so that it is not subject to
mechanical stress (Pic. 5 and Pic. 6).
Property damage caused by drilling through the lock: The lock must be re-
moved for any work on the door leaf, such as drilling or cutting.
Damage caused by dirt: Prior to installation, the lock pocket and all holes must
be cleaned (by blowing out or vacuuming).
Functional limitation due to distorted installation: The lock must be installed
free of torsion.

Installing the Espagnolette

The OneSystem Espagnolette uses the ASSA ABLOY Easy-Installation assembly
ASSA ABLOY
system. A synthetic wire is used to attach the flush bolt rods to the lock case, the
Easy-Installation
wire is threaded through the flush bolt rods and used as a guidance to fasten
assembly system
them into the correct position.
I
Note!
The lower flush bolt rod is optional. The corresponding steps are not performed
if the lower flush bolt rod is not required.
