Use
4.4.3 Settings
This menu displays the basic configuration of the selected device. Scroll through the various
menu items via touch. Tap on or to change settings directly or go to different submenus.
Datum / Uhr: Display of time and date of the Home Server
Language: Select the menu language.
Currency: Select a currency symbol.
Temperature Unit: Defined as °C.
Temperature Limit: The temperature limit can be activated / deactivated in this menu and
the maximum outlet temperature can be limited to a desired value within the temperature set-
ting range by tapping on or .
Note: If the instantaneous water heater is supplied with a remote control and the device
powers a shower, then the maximum temperature was limited during the installation of
the device and can only be changed below this temperature. The temperature limit can-
not be fully deactivated in this case.
Activation of a temperature limit applies to all users and is not just saved as an app-
specific value.
Flow Limit: Setting of flow rate limitation (only devices with Servotronic®).
Setting options:
"OFF" no flow rate limitation (motor valve deactivated)
"AUTO" automatic adjustment, i.e. flow rate is limited in a way so that the selected outlet
temperature is reached
"ECO" flow rate limitation to max. 8.0 l/min
e.g. "9.0" limitation to a freely selectable value between 4.5 and 25 l/min
Note: If the Eco function has been activated in the menu "Savings", the flow is automati-
cally set to "ECO". Changing the flow to a higher value than 8 l/min deactivates the Eco
function
Activation of a flow limit applies to all users and is not just saved as an app-specific
value.
Factory Settings: All factory settings for the app or the selected instantaneous water heater
can be recalled:
Note: All customised user profiles, and power and water prices entered, are deleted. If a
load shedding relay is connected, the correct value must be reset under "Load shedding".
Delete Statistics: Use this function to delete all previously collected statistical data. Deleted
