Manufacturer:
Scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
we wish you a pleasant and successful working experience
with your new scheppach machine.
Advice:
According to the applicable product liability law the man-
ufacturer of this device is not liable for damages which
arise on or in connection with this device in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non authorized skilled workers,
• installation and replacement of non-original spare
parts,
• improper use,
• failures of the electrical system due to the non-
compliance with the electrical specifications and the
VDE 0100, DIN 57113 / VDE 0113 regulations
We recommend
that you read through the entire operating instructions be-
fore putting into operation.
These operating instructions are to assist you in getting to
know your machine and utilize its proper applications.
The operating instructions contain important notes on how
you work with the machine safely, expertly, and economi-
cally, and how you can avoid hazards, save repair costs,
reduce downtime and increase the reliability and service
life of the machine.
In addition to the safety requirements contained in these
operating instructions, you must be careful to observe your
country's applicable regulations.
The operating instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously. Only
persons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.
In addition to the safety requirements contained in these
operating instructions and your country's applicable reg-
ulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.
General notes
• After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults.
• Later complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
• Use only original scheppach accessories, wearing or
replacement parts. You can find replacement parts at
your scheppach dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
lcs 400
Delivery status
Firewood chop saw lcs 400
Technical data
Dimensions L x W x H
400/30/3,2/2,2 WZ36
ø Saw blade
ø cutting mm
ø cutting mm in
reverse
Table dimensions mm
Table height mm
Weight
Drive
230 V/50 Hz
Motor V/Hz
Performance input
3,1
P1 kW
2,35
Output power P2 kW
Operation mode
Rated idling
2730
revolution speed rpm
yes
Undervoltage cutback
yes
Motor protection
Subject to technical changes!
Noise characteristic values
Measurement conditions
The values stated are emission values and are therefore
not necessarily safe operating values. Although there is a
correlation between emission and immission levels, you
cannot reliably deduce from this whether additional safety
measures are required or not. Factors which can influence
the immission level currently at the workstation comprise
the duration of the effects, the characteristics of the work
room, other sources of noise etc., for example, the number
of machines and adjacent operations. The permissible val-
ues per workstation can also vary from country to country.
This information should nevertheless enable the user to
make a better estimation of dangers and risks.
Sound level in dB
Idling L / Processing L = 98/102 dB(A)
WA WA
Sound level at the workplace in dB
Idling L / Processing L
pAeq pAeq
A measurement uncertainty allowance K = 4 dB applies to
the mentioned emission values.
Information on dust emission
The dust emission values measured in accordance with the
„principles for testing dust emission" of the committee
of experts of wood are below 2 mg/m3. This means that
the TRK limit for wood dust which is valid in the Federal
Republic of Germany will be permanently kept to if the
machine is connected to a properly working dust extractor
with at least 20 m/s air speed.
Symbols used
ATTENTION
Rocker extension
Saw blade wrench
Accessories bag
Operating manual
1150/760/1490
160
200
750 x 450
860
69,0
400 V/50 Hz
4,2
3,35
S6/40 %
2830
yes
yes
= 79/85 dB(A)
Wear ear
protection
english 9
