4 Pull both steering arms outwards and push the saw
blade cover (C) upwards. Fig. 7.1
5 Tighten the two bolts (A+B) in this position and remove
the cover (D). Fig. 7.2
6 Secure the saw blade with the securing pin and open
the saw blade bolt (E) with the socket spanner.
7 Remove the nut and the saw blade flange.
8 Remove the saw blade carefully.
9 Before you insert the new saw blade, clean the flange
with a rag or brush.
10 Insert the new saw blade and secure it with the flange
and the hexagon nut. Attention: check that the direc-
tion is correct.
11 Replace the saw blade cover and the joint connec-
tion.
Check the correct function by lowering.

EC Declaration of Conformity

We herewith declare, Scheppach
Holzbearbeitungsmaschinen GmbH, Günzburger Str. 69,
D-89335 Ichenhausen that the machine described below
due to its con struc tion and design and in the version
delivered by us complies with the relevant provisions of
the following EC Directives.
In case of a modification of the machine this declara tion
ceases to be valid.
Machine description:
Firewood Chop Saw
Machine model:
lcs 400, Art.-Nr. 1540 0901, 1540 0902
Relevant EC directives:
EC machine directive 98/37/EG (< 28.12.2009),
EC machine directive 2006/42/EG (> 29.12.2009),
EC Low voltage directive 2006/95/EWG,
EC-EMV directive 2004/108/EWG.
Applied harmonized European Standards:
EN 1870-6, EN 12100-1, EN 12100-2, EN 13857, EN 349,
EN 13850, EN 1088, EN 60204-1, EN 55014, EN 60555-
2, EN 50082-1, EN 60555-3, EN 61029-1, EN 61029-2-1,
EN 60825-1
Applied european Standards:
EN 847-1, EN 954-1
Applied national technical standards and specifications,
especially:
ISO 7960
Notified body within the meaning of Annex VII
TÜV Rheinland, Product Safety GmbH, 51101 Köln
Engaged for
EG-Baumusterprüfung,
GS-Zertifikat
Date
Ichenhausen, 14.10.2009
Signature:
on behalf of Wolfgang Windrich (product manager)
Fabrikation von
english 13
