Maxxus 90 PRO Bedienungs-/Montageanleitung Seite 28

Teileliste
Teil Beschreibung
43 CRANK L
44 CRANK R
45 Console
45-1 Console housing down
45-2 Console housing up
45-3 IPHONE Holder
45-4 Air outlet
45-5 Arch pressing plate
46 One-way spontaneous electric
47 Belt pulley axle
48 Belt pulley
49 Motor belt
50 OUTER COVER L
51 OUTER COVER R
52 FRONT FIX COVER
53 REAR FIX COVER
54 CRANK COVER
55 Front stabilizer cover L
56 Front stabilizer cover R
57 Handlebar cover front
58 Handlebar cover rear
59 Back cover of outer cover
60 Cover R
61 Cover R
62 Bottle holder
63 Seat cover L
64 Seat cover R
65 Seat post sleeve
66 Pedal L
67 Pedal R
68 Handle knob bolt
69 Saddle
70 Handle knob
71 Feet pad
72 Wheels
73 Tube plug
74 Tube plug
75 Seat post sleeve
76 Crank cover
77 Upright post wiring
78 Main frame wiring
79 Magnet sensor
Ausführung
B11/228.3x78.5x51
B11/228.3x78.5x51
Ø108x192
Ø308.9x22.2
480PJ8
B11/1089x103.5x632.5
B11/1089x103.5x632.5
B11/167x117x226
B11/130.8x73.5x15
B11/Ø174x16
B11/151.5x154.5x66.2
B11/151.5x154.5x66.2
B11/289x168.5x144
B11/312x168.5x88.7
B11/135x71x79.2
B11/164.4x230.5x30.8
B11/164.4x230.5x30.8
B11/152.5x133x80.5
B11/255.3x105x30.5
B11/255.3x105x33
B11/100x50x120
8020/JD-36A
8020/JD-36A
BLA82/Ø66xM16xØ8
Ø66xM10x25
Ø49x22xM10x26
Ø54.5x23.5
BLF82xØ39xØ30x27.5
B11/95x45x40
B11/L-1200mm
B11/L-1350mm
B11/L-800/2PI
28
Anzahl
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
2
2
2
1
2
2
1
1
