This amplifier is particularly well suited for playing
back the stereo signal of a computer with higher
quality loudspeaker boxes compared to conventio-
nal PC loudspeakers. The connection diagram for
using the SparkII in a PC system is shown below.
For this purpose, with the amplifier switched off,
connect the computer's high-level output (generally
3.5 mm jack plug, usually green) with the ampli-
TYPICAL SETUP
fier's input "AUDIO INPUT". The loudspeakers must
be connected, each with a loudspeaker cable, to
the two loudspeaker outputs "R" (right) and "L"
(left) in the connection area "TO SPEAKER". If the
audio signal of the computer is to be recorded, con-
nect the recording output "AUDIO OUTPUT" (9) to
the high level input of a recording device (tape, CD
recorder etc.).
