Thomashilfen Ronja Reha Bedienungsanleitung Seite 30

2. Installing your child seat (rearward facing) in
IMPORTANT - This child seat has been designed to perform safely and independently of further external restraint.
2a
2b
2c
2d
30
IMPORTANT - The child seat
seat belt.
The child seat has an adjustable support leg
more reclined the seat must be.
The larger the child the more upright the seat must be. To change the position
(if required) pull the support leg clips off of either side and slide the telescopic
leg in or out (dia 2b). Once satisfied with the position of the support leg, refit
the clips in the holes (inset). Make sure the hole positions chosen are the
same on both sides.
Place the child seat rearward facing on the car seat. After installation the gap
between the seat in front and child seat should be a minimum of 10mm.
It must NOT rest against the car seat. If it does then adjust the car seat in front
without making the driver or passenger sit in an uncomfortable position. If not
try another seating position in the car
Extend the footprop fully and make sure that the footprop tether brackets are
facing forwards and that the straps are not twisted. Lower the footprop and
adjust the height so that it is within approximately 30mm of the floor
(dia 2c). Use the ruler printed on the back page of this manual to get the
correct distance from the footprop to the floor.
2e
3
2
4
rear side seat
MUST only be used with a lap and diagonal
(dia 2a). The smaller the child the
(dia 2c).
Slide the loop ends of the tether straps
between the front car seat and back as
shown (dia 2d &
buckle ends of the tether straps around
the outside of the car seat and feed
through the loops
of the tether straps onto the tongues
on the sides of the child seat
Provisionally tighten the tether straps by
pulling the loose ends downwards
dia 2e). Bring the
2 . Snap the buckles
.
3
.
4
