7. Dimensions

Specii cations and appearances of the products are subject to change for improvement
without prior notice.
DK830SR
88.4
39.6
DK830SLR
88.4
39.6
DK830SVR
8.6
8
(E)
195.2
45.7
Thickness:
t=15.2 mm
Cable length: 0.3 m
185.5
45.7
169.4
154.5
57.3
45.7
138.4
17
2-φ4.5 hole
110
(101)
Cable length: 2 m
φ4.8
10.2
φ4.8
φ 8
10.2
Unit: mm
