12.2

"Info" menu

Actuating the "Info" symbol
shown in this menu item are not relevant for the operator of the GSM modem. They only serve the
modem and/or software developers to test and localise a functional fault.
12.3

Function buttons

13.

Technical data

LED CON status
OFF
64 ms ON / 800 ms OFF
64 ms ON / 3000 ms OFF
64 ms ON / 300 ms OFF
Operating conditions
Supply voltage
Ambient operating temperature
Storage temperature
Current drawn
Data mode, GPRS Class 10I@PCL5
Average Idle
Sleep mode @ DRX9
in the Status display opens an additional information menu. The data
Return to the previously selected menu, or abort when making an entry.
Actuating this button opens the "Modem fault" menu.
The faults occurring during modem operation are shown here.
Faults can be acknowledged here provided that they are no longer pending.
This button enables the modem's function to be tested.
Actuating this button sends a Status SMS to the target phone numbers.
Meaning
switched off
not registered in network
registered in network
GPRS communication exists
Limits
4.75 – 5.25
-30° - +80°
-40° - +85°
typical
350
22.0
1.0
Operating and installation manual for GSM mode
maximum
450
25.0
1.5
Page 26
903 501 - V1.0
Unit
VDC
°C
°C
Unit
mA
mA
mA
