④ Max/Min values of the current measurement range
⑤ Curve Diagram: Graphically displays the variation trend of the current measurement data.
⑥Press the button to exit the current multimeter function and return to the previous menu or
operation interface.
▶3.3.2 Test Lead Interface Description
① High current measurement: Red lead to 10A, black lead to COM
Note: Measuring current over 10A will damage the fuse. Please estimate before testing.
② Low current measurement: Max 199.99mA. Red lead to mA, black lead to COM.
③ Voltage, resistance, capacitance, temperature, diode/continuity measurement: Red lead to
, black lead to
1 2 3
. Select corresponding function range based on measurement type.
