Technical Data - BURG WÄCHTER secuENTRY easy PINCODE Montageanleitungen

Hint: The QR code can also be stored in an electronic form as a scanned file
or a photograph on a protected data carrier.
Additional functions available using the optional secuENTRY easy
Software, for example:
• User administration
• Assignment of authorisations
• History functions
Power supply
• 2 x MIGNON LR6 AA ALKALINE for the keypad
• 2 x MIGNON LR6 AA ALKALINE for the cylinder
Optical signalling
Optical signalling in the form of a LED is incorporated in the knob on
the outer side of the door. This LED informs you on the following:
• 1 x brief: cylinder coupled
• 2 x brief: cylinder uncoupled
• 1 x brief, 1 x long, 2 sec pause, repeating: lock in programming mode
• 5 x briefly, 2 sec pause, repeating at 20 sec: battery in cylinder empty

Technical data

Blocking times
Display
Permissible
ambient
conditions *
Keypad
protection class
Transmitting power
and frequency
range:
* In case the temperature exceeds the specified range, a corresponding warning message is
indicated on the display. Provide for appropriate corrective action!
secuENTRY easy
After 3 × wrong code is entered 1 minute,
then always 3 minutes
Adjustable to 12 languages
-15 °C / +50 °C / up to 93 %
rel. air humidity (noncondensing)
Allowed temperature range: -20 °C / +50 °C
As a result of extreme temperature changes,
the display can react slowly or darken.
Protection class keypad PINCODE IP65
Protection class keypad Fingerprint IP55
Bluetooth Low Energy
Maximum Transmit Output Power 7,5dBm
Frequency usage range 2,402GHz ... 2,483 GHz
English | 25
