Illustration
On key
Activation of the keypad for the entry of the opening code.
Enter key
Selection of a menu item.
Function key
The function key provides for a variety of actions depending on
the current status of the keypad. The display indicates, which function
is active.
1) Access to the menu for programming
When the "Func:M" symbol is displayed, the menu can be reached
by pressing the "Func" key. In the menu, the keys "1" and "2" can be
used as a scroll function to navigate through its structure.
2) Deleting an entry action
When the "Func:C" symbol is displayed, the last entry can be cancelled
by pressing the "FUNC" key.
3) Entry to previous programming level / Back
When you are in the menu, the symbol "Func:<" is displayed.
By pressing the "FUNC" key, you return into the menu structure on
the next higher level.
Battery indicator
The display indicates battery statuses of the cylinder unit and the keypad
unit. The indication on the display concerns the batteries with the lowest
status. In case a battery is empty, the display indicates as follows:
Replace battery in keypad or replace battery in knob.
When the battery has been replaced and then the opening code entered
twice, the currently lowest battery status is displayed. When only a single
battery set is replaced, the display can still indicate an "incomplete"
status, despite the replacement. In case you do not replace the batteries
in spite of the replacement indication, you will have to enter the valid
opening code once more in order to open the door. At the same time,
the inner knob LED flashes 5 x 5 times. You can still open the door in this
way approx. 50 times. Then it can only be opened using the administrator
code. Now the batteries must be replaced, otherwise the door cannot be
opened any more.
Fingerscan sensor
To open or register the particular finger.
sy secuENTRY easy
Battery full Battery empty
English | 23
