Maxxus BTX 1 Montageanleitung Und Bedienungsanleitung Seite 26

Teileliste
Nr.
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
85
86
87
88
89
90
91
92
26
Bezeichnung
Button Head Plug
Frame Base Cover (R)
Frame Base Cover (L)
Frame Base Front Wheel
Frame Base Rear Wheel
Motor Cover Anchor
Motor Top Cover
Top Motor Cover Plate
Front Motor Cover
Footrest (L)
Footrest (R)
Foot Rail
Rear Foot Rail
Rear Adjustment Base (L)
Rear Adjustment Base (R )
Rear Foot Cover
Cushion
Rear Up/Down Adjustable Foot
Ø10 × Ø24 × 3T_Nylon Washer(A)
Ø50 × Ø13 × 3T_Nylon Washer(B)
½" × 1-1/4"_Carriage Bolt
1/2" × 1"_Hex Head Bolt
3/8" × 4"_Hex Head Bolt
3/8" × 92m/m_Hex Head Bolt
3/8" × 1"_Hex Head Bolt
3/8" × 1-1/2"_Hex Head Bolt
3/8" × 45m/m _Hex Head Bolt
3/8" × 2"_Flat Head Socket Bolt
5/16" × 1"_Button Head Socket Bolt
M8 × 60m/m_Hex Head Bolt
M8 × 65m/m_Socket Head Cap Bolt
M8 × 25m/m_Flat Head Countersink Bolt
1/2" × 8T_Nyloc Nut
3/8" × 7T_Nyloc Nut
5/16" × 6T_Nyloc Nut
M8_Nyloc Nut
3/8" × 7T_Nut
Ø35 × 5/16" × 1.5T_Flat Washer
Ø25 × 10 × 2.0T_Flat Washer
Ø19 × 10 × 1.5T_Flat Washer
3/8" × 2.0T_Split Washer
M5_Star Washer
4 × 12m/m_Sheet Metal Screw
5 × 16m/m_Tapping Screw
5 × 19m/m_Tapping Screw
5 × 16m/m_Tapping Screw
3.5 × 12m/m_Sheet Metal Screw
4 × 38m/m_Sheet Metal Screw
3.5 × 16m/m_Tapping Screw
Anzahl
2
1
1
2
2
2
1
1
1
1
1
4
2
1
1
2
6
2
3
4
2
2
1
1
4
1
1
2
4
1
2
8
4
6
2
1
3
2
4
6
4
3
4
37
7
10
12
2
5
