Using two 10-32 x 0.5 Phillips screws, secure the back mounting-bracket flange to the
5
back vertical rail.
Repeat steps 1 through 5 for the remaining mounting rail on the other side of the rack.
6
Ensure that the mounting rails are mounted at the same position on the vertical rails
7
on each side of the rack.

Installing the Tower-to-Rack Conversion Kit

NOTE: If you have a rack-only version of the system, skip this procedure and proceed to
"Installing the System in the Rack."
CAUTION: Your system may be very large and heavy. To prevent personal injury,
do not attempt to move the system by yourself.
The tower-to-rack conversion kit includes a rack front panel with rack handles and
thumbscrews.

Removing the Bezel, Drives, Covers, and Front Panel

Shut down and turn off power to your system and disconnect your power and
1
peripheral cables.
To remove the bezel (see Figure 1-7):
2
a
b
c
d
1-10 Rac k I nst allat io n G uide
Using the system key, unlock the front bezel.
Swing the bezel away and down from the system until it is perpendicular to the
system.
Loosen the two thumbscrews that secure the bezel hinge to the front panel (see
Figure 1-7).
Pull the bezel away and set it aside.
