PCL APP700SET Bedienungsanleitung Seite 3

4. OPERATION
4
1
5
Description
1 Trigger/Safety Lever
2 Compressed Air Inlet
3 Exhaust
4 Collet (6mm)
5 Collet Spanner (19mm)
6 Collet Spanner (14mm)
Be sure to use the correct air compressor with air-powered tools. The compressor should be able to
supply a minimal air delivery of 6.36 SCFM @ 90 psi to ensure the compressor can run continuously with
the tool.
Always use clean, dry regulated compressed air.
Description
1 Air Tool
2 Adaptor
3 Coupling
4 Air Hose
5 Lubricator
6 Regulator
7 Filter
8 Cut-off valve
9 Air compressor
76629 Issue 1
6
www.pclairtechnology.com
