TREND VARIJIG Übersetzung Der Originalanleitung Seite 7

shape can be replicated.
• As the guide bush is bigger than the
cutter there will be an offset. This
offset will need to be calculated when
setting frame size.
• Shank mounted bearing guided cutters
can also be used, please note however
that extra care must be taken as the
cutting edge may scratch the frame
edge. The router sits on top of the
frame. If the router has a base smaller
than 170mm diameter, the Unibase
circular sub-base can be fitted to the
router, and this can follow the inside
edge of the router.
WARNINGS
Ensure the cutter diameter
will pass through the guide bush
leaving at least a 3mm clearance.
– (Fig.9)
Ensure all fixing screws are
tight.
The guide bush should have
a projection of minimum 8mm.
Suggested guide bushes are:
30mmØ Ref. GB30/A
40mmØ Ref. GB40/B
Ensure working position is
comfortable when routing. Keep
proper footing and balance at all
times.
Adjusting Frame for Size
– (Fig.10, 11 & 12)
• Ensure the jig is sitting correctly and
clamped securely to the component.
Ensure component is clamped
properly.
• Only loosen silver screws to adjust
frame. After every adjustment, the
frame will need to be checked for
squareness.
Clamping Varijig Frame
– (Fig.13)
• When using battens ensure the pins do
not foul the path of router. The battens
should have a thickness of maximum
12mm. Four battens will be needed.
Routing Squares and Rectangles
Square for Panels – (Fig.14)
Rectangle for Housing and
Trenching – (Fig.15)
Feed Direction – (Fig.16)
Turning Corners with Anti-tilt
Shoe Fitted – (Fig.17)
• Ensure the anti-tilt shoe is fitted and
secure. Ensure guide bush and cutter
is fitted to the
• Set the cutter depth.
• Place router onto Varijig with the anti-
tilt shoe sitting on the component.
• Place router so that guide bush is
touching the inside edge of the frame
and switch on router. Plunge down and
rout in a clockwise direction keeping
the guide bush against the frame edge.
• At the corners carefully rotate the
router so the anti-tilt shoe does not
touch the frame, complete routing until
routed square or rectangle is complete.
• After on one circuit, release plunge
and switch off router. Repeat operation
until final depth of cut is achieved.
After use of the jig it is advisable to
keep jig assembled and store safely.
• Please note corners will be rounded
and not square due to rotary cutting
action of the cutter. – (Fig.18)
Infill Corner Pieces – (Fig.19)
• MDF corner pieces can be user made
and hot melt glued into the corner of
the frame to allow decorative panel
effects to be created. The corner
pieces must be of a suitable thickness.
ACCESSORIES – (Fig.20, 21 & 22)
Please use only Trend original
accessories.
Friction clamps are available. One clamp
is fitted at either end of the extrusion.
Tighten friction screw with No.2
Phillips® screwdriver.
Ref. VJS/CK - Sliding friction clamp
(pair). Clamping thickness 32mm (1-
1/4").
Ref. VJS/CK/L - Sliding friction clamp
(pair). Clamping thickness 51mm (2").
Ref. VJS/PCK/L - Pivot head sliding
friction clamp (pair). Clamping thickness
51mm (2").
MAINTENANCE
Please use only Trend original spare
parts and accessories. The accessory
has been designed to operate over a
long period of time with minimum of
maintenance. Continual satisfactory
operation depends upon proper tool
care and regular cleaning.
Cleaning
• Keep the grooves on the extrusion and
knob threads clear of sawdust.
• Regularly clean with a soft cloth.
Lubrication
• Your accessory requires no additional
lubrication.
Storage
• This jig should be stored safely on wall
hooks after use.
Spare Parts
• See website for details
- 7 -
VARIJIG
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of
disposing as waste.
Packaging should be sorted for
environmentally friendly recycling.
This product and its accessories at
the end of its life should be sorted for
environmental-friendly recycling.
WARRANTY
This unit carries a manufacturer's
warranty in accordance with the
conditions on our website
www.trend-uk.com
DE – VARIJIG
Vielen Dank, dass Sie sich für dieses
Produkt von Trend entschieden
haben. Bitte beachten Sie diese
Bedienungsanleitung. Nur so wird eine
dauerhafte Leistung sichergestellt.
TECHNISCHE DATEN
Profildicke
Profilbreite
Arbeitsbereichsgröße
max
Führungseinsatz
Länge (min.)
Gewicht
In diesem Handbuch werden die
folgenden Symbole verwendet:
Informationen hierzu finden
sie in der bedienungsanleitung
ihres elektrowerkzeugs.
Bezeichnet die Gefahr von
Personenschäden, Lebensgefahr oder
Beschädigung des Werkzeugs bei
Nichtbeachtung der Anweisungen in
diesem Handbuch.
Dieses Gerät darf erst in Betrieb
genommen werden, wenn festgestellt
wurde, dass das an dieses Gerät
anzuschließende Elektrowerkzeug der
Richtlinie 2006/42/EG (gekennzeichnet
durch die CE-Kennzeichnung am
Elektrowerkzeug) entspricht.
VERWENDUNGSZWECK
Die Vorrichtung ermöglicht das Fräsen
einer Vielzahl von Quadraten und
Rechtecken mit einer handgeführten
Oberfräse mit Führungseinsatz und
passendem Fräser.
SICHERHEIT
Bitte lesen und beachten Sie die
15.8mm (5/8")
54mm (2 1/8")
600mm x 600mm
(23 5/8" x 23 5/8")
8mm (5/16")
2.1kg (4.6lbs)
