MACHINE OVERVIEW

12
3
4
5
1. VARIABLE SPEED TRIGGER
2. SAFETY LOCK-OFF BUTTON
3. BLADE CLAMP
4. PARALLEL EDGE GUIDE CLAMPING SCREW
5. SAW BLADE
6. PARALLEL EDGE GUIDE
7. PENDULUM CONTROL
www.evolutionpowertools.com
2
8. BASE PLATE
9. DUST PORT
10. BATTERY
11. BEVEL ADJUSTMENT
12. LED LIGHT
