Press and hold for 5 seconds (in
shutdown mode)
Charging Contacts
8.
For connecting the receiver to a charger.
Belt Clip
9.
Allows the receiver to be mounted onto a camera.
CC Charging Case
Charging Contacts
1.
For charging transmitters.
Slot for Transmitters
2.
Designated slots to securely hold and charge the transmitters.
Slot for Receiver
3.
Designed slot to store and hold the receiver.
Charging / Remaining Battery Level Indicator
4.
When the charging case is connected to power, this indicator will display the
case's charging status:
Status
Low battery
Charging
Fully charged
When the charging case is not connected to power and the transmitter(s) is
placed into it for charging, the indicator will display the case's remaining battery
level:
Enter pairing mode
Battery Level (Case)
30% or lower
31% ~ 99%
100%
13
Rapid blinking blue (5
minutes)
Indicator
Blinking red
Blinking green
Static green
