Assembly and installation
Fig. 11: Splash Control 2 with connected DGMa and bridges on the non-assigned terminals.
4.9

Cable Cross-Sections and Cable End Sleeves

Without cable end
sleeve
Cable end sleeve
without insulation
Cable end sleeve with
insulation
4.10

Electrical fuses

Parameter
Electrical fuse
26
Minimum cross-sec‐
tion
0.25 mm
2
0.20 mm 2
0.20 mm
2
Specification(s)
Glass fuse, 5x20 , slow-acting, 250 mA
Glass fuse, 5x20 , slow-acting, 3.15 A
Maximum cross-sec‐
tion
1.5 mm
2
1.0 mm 2
1.0 mm
2
A2921
Stripped insulation
length
8 - 9 mm
10 - 11 mm
Markings(s)
F3
F2
