Installation (Electrical) - Prominent Dulcopool Montage- Und Betriebsanleitung

2
1
Fig. 5: Fitting the wall bracket
6. Hook the bottom of the housing (1) into
the wall bracket
7. Lightly press the housing at the top (2)
against the wall bracket
8. Then check that the housing is hooked
in at the top and press down (3) until it
audibly engages
4.3

Installation (electrical)

WARNING!
Failure of the circulating pumps
In the event that the circulating pump
fails, the control for the corresponding
swimming pool has to be stopped. It is
not sufficient to use the in-line probe
housing's sample water limit contact
alone. You need to take appropriate
3
additional measures.
The following are suitable as triggers
for the measures:
A0492
– the potential-free contact of the
filter control,
– the potential-free contact of the cir‐
culating pump's motor protection
switch,
– a flow monitor in the circulation
line.
Assembly and installation
19
