TYPICAL APPLICATION A
Assignment
Head Unit Amplifier
RCA RCA
Outputs Inputs
RL/SUB OUT L
RR/SUB OUT R
TYPICAL APPLICATION B
Assignment
Head Unit Amplifier
RCA RCA
Outputs Inputs
RL/SUB OUT L
RR/SUB OUT R
