Connection components for installation
1 Hose connector, transparent
• Use: Water outlet, dirt water outlet
2 Hose connector, black
• Use: Water inlet
3 Hose connector, black with G2 outer thread
• Use: Open end of the dirt water hose, the cover cap is screwed onto the outer thread
4 Union nuts G2, for installing the hose connectors
5 Cover cap G2, for closing the dirt water outlet
6 Flat seal for black hose connector and cover cap
7 Flow lug for transparent hose connector
8 Hose clip
