All replacement parts are available from you local KESSEL aut-
5.1
horized dealer or from KESSEL directly if no dealer is available
in your area.
-Comfort control unit – IP 54
Description Ecolift®
➀
a) Potential free contact
b) Remote alarm unit with 20 meter cable
c) 9-volt battery for control unit (2 required)
Optical probe IP 68 (5 meter cable incl. adapter )
➁
Pump cover inlet side (without floor drain function)
➂
-cover outlet side
Ecolift®
➃
-pump IP 68 (5 meter cable incl. plug)
Ecolift®
➄
Ventilation system (complete)
➅
a) Activated charcoal filter
Motorized backwater flap
➆
Housing for motorized flap
➇
Motor for motorized flap IP 68 (5 meter cable)
➈
Gasket set II
for installation in concrete floors (underground)
5.2 Ecolift
All replacement parts are available from your local KESSEL
authorized dealer or from KESSEL directly if no dealer is avai-
lable in your area.
-Comfort control unit – IP 54
Description Ecolift®
➀
a) Potential free contact
b) Remote alarm unit with 20 meter cable
c) 9-volt battery for control unit (2 required)
Optical probe IP 68 (5 meter cable incl. adapter)
➁
Pump cover inlet side (with floor drain function
➂
-cover outlet side
Ecolift®
➃
-pump IP 68 (5 meter cable including plug)
Ecolift®
➄
Ventilation system (complete)
➅
6a) Activated charcoal filter
Motorized backwater flap
➆
Housing for motorized flap
➇
Motor for motorized flap IP 68 (5 meter cable)
➈
Gasket set II

5. Replacement Parts

21071
Art.-No.
80072
20162
197-081
80888
28052
21056
28351
28060
28061
80038
80039
80076
70319
21071
Art.-No.
80072
20162
197-081
80888
28054
➂
21056
28351
28060
28061
80038
80039
80076
70319
21
➁
➄
➀
a,b,c
a
➆
a
➀
a,b,c
➁
