Roborock Saros 10R Bedienungsanleitung Seite 8

A11-12—Drain Port
A11-13—Cleaning Tray Filter
A11-14—Drying Air Outlets
A11-15—Dock Location Beacon
A11-16—Suction Inlet
A11-17—Robot Refill Port
A11-18—Cleaning Tray Module
A11-19—Water Level Float
A11-20—Clean Water Dispensers
Installation
B
Important Information
B1
B1-1— Tidy cords, hard or sharp objects
(such as nails and glass), and loose
items from the ground and move
any unstable, fragile, precious,
or dangerous items to prevent
personal injury or property damage
due to items becoming tangled in,
struck by, or knocked over by the
robot.
B1-2— When using the robot in a raised
area (such as in a duplex apartment),
always use a physical security barrier
to prevent accidental falls that may
result in personal injury or property
damage.
Notes:
• When using the robot for the first time, follow it
throughout its whole cleaning route and watch for
potential problems. The robot will be able to clean by
itself in future uses.
• To prevent excessive buildup of dirt on the mop cloths,
floors should be vacuumed at least three times before
the first mopping cycle.
Assembly
B2
B2-1—Attach the dock base by pressing
down both sides of the base and the
connecting part in the middle firmly
until you hear a click.
Note:
When moving the dock, secure the water tanks to
prevent them from falling off.
B2-2— Connect the power cord to the back
of the dock, and the power cord can
exit at either the left or right cord
slot opening.
B2-3— Align and install the mop axles into
the robot in place until you hear a
click.
Positioning the Dock
B3
Place the dock on a hard, flat floor (wood/
tile/concrete etc.), flat against a wall, and
reserve a space of at least 0.75 m (2.46 ft)
in height, 0.4 m (1.31 ft) in width and
1.2 m (3.94 ft) in depth. Make sure that
the location has good WiFi coverage for a
better experience with the mobile app. Plug
in and make sure that the status indicator
light is on.
B3-1—More than 1.2 m (3.94 ft)
B3-2—More than 0.75 m (2.46 ft)
B3-3—More than 0.4 m (1.31 ft)
Notes:
• If the power cord hangs vertically to the ground, it
may be caught by the robot, causing the dock to be
moved or disconnected.
• The status indicator light is on when the dock is
007
powered on, and off when the robot is charging.
• The status indicator light turns red if an error occurs.
• Place the dock on a hard, flat floor away from fire,
heat, and water. Avoid narrow spaces or locations
where the robot may be suspended in the air.
• Placing the dock on a soft surface (carpet/mat)
may cause the dock to tilt and cause docking and
departing problems.
• Keep the dock away from direct sunlight or anything
that may block the dock location beacon, otherwise
the robot may fail to return to the dock.
• Do not use the dock without clean water tank, dirty
water tank, dust container cover, disposable dust bag,
cleaning solution cartridge, or cleaning tray module.
• Maintain the dock according to the Routine
Maintenance. Do not clean the dock power cord and
charging contacts with a wet cloth or tissue.
• All docks are subject to water-based tests before
leaving the factory. It is normal that a small amount of
water remains in the waterway of the dock.
Powering On & Charging
B4
Press and hold to power on the robot.
Wait until the power indicator light is
steady, and then place the robot in
front of the dock. Make sure the dock is
plugged in. Then, press and the robot
will automatically return to the dock for
charging. The robot is equipped with a
built-in high-performance lithium-ion
rechargeable battery pack. To maintain
battery performance, keep the robot
charged.
B4-1— Dock status indicator light off, robot
power indicator light breathing:
Charging.
Note: The robot may not be turned on when the battery
is low. In this case, place the robot to the dock for
charging.
