device from your body in case of
danger.
NOTICE! Pulling the push-fit lock (16)
releases the device quickly from the
carrying strap (15). To open the push-
fit lock, press the two clamps togeth-
er.
Putting on the carrying strap
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop
2. Place the carrying strap (15) on
one shoulder.
3. Adjust the length of the strap so
that the snap hook is approxim-
ately 10 cm below your hip.
4. Attach the snap hook on the eyelet
(17) to insert the carrying strap.
Sliding the eyelet (Fig. F)
Slide the eyelet (17) to better spread
the weight of the device.
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop
2. Loosen the hexagon socket screw
(38) on the eyelet (17).
3. Slide the eyelet to the appropriate
position.
4. Tighten the hexagon socket screw
again.
Adjusting the auxiliary
handle
Adjusting the position (Fig. G)
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop
2. Fold open the lock (10).
3. Move the auxiliary handle (18) to
the desired position.
4. Fold the lock closed to fix the pos-
ition.
Adjusting the angle (Fig. G)
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop
2. Loosen the quick-release lever
(39).
3. Set to the desired angle.
4. Close the quick-release lever.
Swivelling out the motor
head
Requirements
• Saw chain assembled
• Chain guard attached
• Tubular shaft assembled
• Motor head assembled
Notes
•
WARNING! Do not make a re-
lief cut with the motor head tilted.
There is a risk of kickback, which
may render the device uncontrol-
lable.
Swivelling out the motor head
(Fig. E)
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop
2. Press and hold the locking button
(37).
3. Turn the motor head (19) into the
desired position.
4 positions are possible.
4. Let go of the locking button (37).
5. Check that the motor head (19) is
engaged in the selected position.
Extending the tubular shaft
Extending the tubular shaft (Fig. C)
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop
