• Once the mounting bracket is installed, verify proper installation before hanging the fan.
The mounting bracket must support the entire weight of the fan.
P RO PE LL E R AS SE MB LY
Insert the propeller into the shaft in the main body and secure it with the help of the stopper.
AS SE MB LI N G THE WOO D E N PI ECE S
Insert the wooden pieces one by one into the notches on the outside of the main body and
into the wooden ring as shown below.
Drill holes with an 8mm drill bit, according to the length of the
expansion screws. Next, secure the mounting bracket to the
ceiling with the expansion screws.
Drill the necessary holes and then secure the mounting bracket
with the special spring-loaded fixing screws for use in false
ceilings.
Concrete ceiling
False ceiling
