Maintenance and storage
• Ensure that all nuts, bolts and screws are
tightened and the tool is in a safe operat-
ing state.
• Check the grass collection equipment
regularly for wear or for loss of functional-
ity.
• For safety reasons, replace worn or dam-
aged parts.
• Remember that when using a tool with
multiple blades, moving one blade may
lead to the other blades rotating.
• When adjusting the machine, make sure that
no fingers are trapped between the moving
blades and fixed parts of the machine.
• Allow the motor to cool down before you
put the machine away.
• When maintaining the blades, remember
that even if the power source is deacti-
vated, the blades can still be moved.
• For safety reasons, replace worn or dam-
aged parts. Only use original spare parts
and accessories.
Your device at a glance
► P. 3, fig. 1
1. Operating lever
2. Handle bar
3. Strain relief mechanism for extension
cable
4. Handle bar, bottom part
5. Protective flap
6. Collection box
7. Mains plug
8. Operating safety lock
Scope of delivery
• Operating manual
• Lawn-mower
• Handle, lower section
• Handle
• Collection box
• Bag containing small parts
Note: If any one of the parts is
missing or damaged contact the
retailer.
Assembly
Mounting the handle
► P. 3, fig. 2
– Position the bottom part of the handle
bar (4) into the locators on the product
and tighten with screws (9).
30
► P. 4, fig. 3
– Push the cable grip (3) onto the handle
bar (2).
– Position the handle bar (2) onto the bot-
tom part of the handle bar and push
through the carriage bolts (10).
– Position the toggle nuts (11) and tighten.
Mounting the collection box
► P. 4, fig. 4
– Assembly both parts of the collection box
and allow to engage.
Operation
Check before starting the device!
DANGER! Risk of injury! The
device may only be put into opera-
tion if there are no defects. If a part
is defective it must be replaced
before the device is used again.
Check to make sure the device is in safe
operating condition:
– Check to make sure there are no visible
defects.
– Check to make sure all device compo-
nents are correctly mounted.
Preparation
Set the cutting height
The cutting height can be set to several different
heights (Cutting heights: ► Technical data – p. 32).
► P. 5, fig. 5
– Allow the axles (12) to engage at the
desired height.
Attach the collection box
► P. 5, fig. 6
– Lift and keep hold of the protective
flap (5).
– Hook in the collection box.
– Make that the collection box is securely
engaged.
Connecting the product
► P. 5, fig. 7
– Pull the extension cable through the cable
grip (3) as illustrated.
– Insert the extension cable coupling into
the mains.
Switching on the product
► P. 5, fig. 8
– Press the operating safety lock (8) and
hold down.
– Pull and keep hold of the operating
lever (1).
